LiftMaster PPV3M Passport MAX 3-Button Visor Remote Control
The LiftMaster PPV3M Passport MAX 3-Button Visor Remote Control is a visor-style remote for a vehicle sun visor used where one transmitter needs to handle multiple secured access points. In the field, Passport MAX remotes are common on gated community entrances, apartment or condominium access systems, commercial door locations, and residential garage openers that support the matching LiftMaster radio technology.
This remote is not just a basic one-button clicker. It is designed for credentialed access-control use and can provide a unique credential ID when paired with supported access-control equipment. That matters for properties that track users, manage tenant remotes, or need better control over who has access to a gate or garage entrance.
Correct receiver matching is the important part. A Passport MAX remote may be associated with PPWR, CAPXL, Security+ 2.0, and Security+ applications, but the exact programming method depends on the equipment at the site. Older DIP systems, non-LiftMaster receivers, and unsupported residential operators may require a different remote.
Compatible With
Commonly Associated Systems and Receivers
- LiftMaster CAPXL access-control systems when configured for compatible Passport remote use
- LiftMaster PPWR Passport Wiegand receiver applications
- Supported LiftMaster Passport access-control installations
- Select LiftMaster Security+ 2.0 residential garage door openers
- Select LiftMaster Security+ 315 MHz and 390 MHz residential garage door openers
- Supported LiftMaster gate operator or commercial receiver installations using Passport MAX remote technology
Related Applications
- Gated communities and multi-tenant properties
- Commercial access-control entrances
- Garage doors and gates controlled from one transmitter when supported by the receiver/operator
- myQ light accessory control when supported by the specific device
Features and Specifications
| Manufacturer | LiftMaster |
|---|
| Product Type | Passport MAX remote control |
|---|
| Part Number | PPV3M |
|---|
| Application | Gate access control, commercial properties, gated communities, and supported garage opener systems |
|---|
| Buttons | 3 |
|---|
| Remote Style | Visor remote |
|---|
| Security Technology | Passport MAX / Security+ 2.0 / Security+ compatible applications |
|---|
| Frequency | Tri-band 310 MHz, 315 MHz, and 390 MHz applications |
|---|
| Compatible Receiver Type | PPWR Passport Wiegand receiver and supported LiftMaster access-control receivers |
|---|
| Notes | Programming and compatibility depend on receiver model, operator technology, and site configuration |
|---|
Also Known As / Related Part Numbers
- PPV3M
- PPV3MMC
- LM-PPV3M
- Passport MAX 3-button remote
- Passport MAX tri-band remote
- PPWR receiver
- CAPXL access-control remote
- Security+ 2.0 remote
- Security+ 315/390 MHz remote
- 114A4720 Passport MAX remote manual reference
Technician Note
When replacing a Passport MAX remote, match the site receiver first. The same remote body style does not guarantee compatibility if the property uses a different credential format, receiver family, or programming restriction.
Before Ordering
- Confirm the receiver or operator model before ordering
- Check whether the site uses PPWR, CAPXL, Passport, Security+, or Security+ 2.0 technology
- Verify whether a visor remote or keychain remote is preferred
- Confirm programming access is available at the receiver, operator, or access-control panel
- For managed properties, confirm whether the remote must be enrolled by a property manager or access-control administrator
Important Ordering Warnings
- Not a universal replacement for every LiftMaster, Chamberlain, or community gate remote
- Not intended for unrelated DIP-only receivers unless the receiver supports the required technology
- Some community systems require administrator enrollment before the remote will function
Professional Advisory
Remote controls should only be programmed to properly installed and adjusted operators or receivers. Keep transmitters away from children and never use a remote when the gate or door path is not clearly visible.
Product Questions and Answers
What receiver does the PPV3M work with?
The PPV3M is commonly used with LiftMaster PPWR Passport Wiegand receivers and CAPXL access-control applications. It may also be used with supported LiftMaster Security+ and Security+ 2.0 garage opener applications when the operator and learn-button technology match.
Is the PPV3M the same as a standard residential garage remote?
No. It is a Passport MAX remote intended for access-control and multi-application use. It can support certain residential LiftMaster garage openers, but it should not be ordered as a generic remote without checking the opener or receiver technology.
What frequencies are associated with Passport MAX remotes?
Passport MAX remotes are commonly associated with tri-band 310 MHz, 315 MHz, and 390 MHz communication, depending on the receiver, access-control system, and programming mode.
Can the PPV3M operate more than one entrance?
Yes. The three-button layout can be used for multiple compatible gates, garage doors, or supported accessories when each button is programmed to the proper receiver or operator.
What should be checked before replacing an older remote with PPV3M?
Check the receiver model, access-control system, learn-button color or programming method, and whether the site uses Passport credentials, Security+ technology, or Security+ 2.0 technology.
