Linear HAE00084 LINEAR600 Light Lens Assembly Service Details
The Linear HAE00084 is the OEM replacement light lens assembly for the Nice/Linear 661 smart residential garage door opener. Current Nice/Linear replacement-parts documentation identifies HAE00084 as the "F/G ASSY, LIGHT LENS, LINEAR600."
The HAE00084 forms the exterior lens over the integrated lighting area of the Linear 661 operator head. It is useful when the original lens is cracked, damaged, missing, discolored, or otherwise requires replacement without replacing unrelated internal operator components.
Compatible With
- Nice/Linear 661 smart garage door operator
- LINEAR600 operator-head service-parts platform
- Original operator assemblies specifically calling for Linear part HAE00084
Compatibility warning: HAE00084 is specifically documented for the Linear 661 / LINEAR600 operator platform. Do not select a replacement light lens by appearance alone. Other Linear LDCO, LDO, LSO, and LCO garage door openers use different lens assemblies.
What the HAE00084 Light Lens Does
The Linear 661 uses integrated LED lighting rather than replaceable conventional light bulbs. HAE00084 covers the lighting area and serves as the replacement light lens assembly for the operator head.
The Linear 661 complete lighting system is rated at 800 lumens. This 800-lumen specification applies to the operator's integrated LED lighting system and should not be interpreted as a light-output rating for HAE00084 itself.
Features and Specifications
| Manufacturer | Nice / Linear |
| Part Number | HAE00084 |
| Product Type | Garage door opener light lens assembly |
| Manufacturer Description | F/G ASSY, LIGHT LENS, LINEAR600 |
| Confirmed Operator | Nice/Linear 661 |
| Service Platform | LINEAR600 |
| Operator Lighting | Integrated LED lighting |
| Complete Operator Light Output | 800 lumens - specification applies to the complete Linear 661 lighting system, not the lens itself |
| Installation Location | Operator head lighting area |
| OEM Service Part | Yes |
| Confirmed Supersession | None confirmed |
| Package Contents | HAE00084 light lens assembly; verify current carton if additional hardware is required |
HAE00084 Is a Lens Assembly - Not the Main Light Electronics
HAE00084 is identified by Nice/Linear as the light lens assembly. Do not confuse the lens with the complete integrated LED lighting electronics or assume that a failed garage light requires replacement of HAE00084.
If the lens is intact but the LED lighting does not illuminate, the failure may involve the lighting electronics, control board, power supply, wiring, wall station command, or another operator component. Diagnose the lighting system before ordering a cosmetic lens to correct an electrical failure.
HAE00084 vs. Other Linear Light Lenses
Linear has used different light lenses across several garage door opener generations. Similar-looking covers are not automatically interchangeable.
- HAE00084: Light lens assembly documented for the Linear 661 / LINEAR600 platform.
- 228152: LDCO light lens documented for LDCO800, LDCO801, and LDCO850.
- 217645: Light lens cover associated with older Linear LDO operator families.
- 220918: Lens cover used with select older LSO and LCO operator families.
Verify the complete garage door opener model and replacement-parts diagram rather than matching a replacement lens by shape alone.
Related Linear 661 Replacement Parts
- HAE00082 - LINEAR600 control board
- HAE00083 - LINEAR600 motor with encoder assembly
- HAE00084 - LINEAR600 light lens assembly
- HAE00085 - LINEAR600 power supply associated with the BATT54 configuration
- HAE00080 - Wi-Fi wall station used with LINEAR600 and select LDCO models
- HAE00087 - safety beam sender and receiver kit
These parts perform different functions and should not be substituted for HAE00084.
Also Known As / Related References
- HAE00084
- HAE-00084
- LINEAR600 Light Lens
- Linear 661 Light Lens
- Nice Linear 661 Light Lens Assembly
- F/G ASSY, LIGHT LENS, LINEAR600
No confirmed replacement or superseding service part number for HAE00084 was found in the current manufacturer replacement-parts documentation reviewed.
When to Replace the HAE00084 Lens
- Original lens is cracked or broken
- Lens is missing from the operator head
- Mounting points on the lens are damaged
- Lens has become heavily discolored or damaged
- Operator requires restoration of the original Linear 661 light-cover assembly
A lens replacement is primarily a housing and lighting-cover repair. If the integrated LED system does not operate, troubleshoot the electrical lighting system separately.
Technician Note
If the complaint is "the garage opener light does not work," inspect the HAE00084 lens first only for physical damage. A clear and undamaged lens does not indicate that the LED lighting electronics are working, and a damaged lens does not necessarily mean the LED electronics have failed.
The Linear 661 uses integrated LED lighting with no conventional bulb to replace. Electrical lighting failures should be diagnosed through the appropriate Linear 661 service procedure rather than attempting to install a standard replacement light bulb.
Before Ordering Checklist
- Confirm the garage door opener is a Nice/Linear 661.
- Verify the replacement-parts diagram identifies HAE00084.
- Compare the original lens shape and mounting arrangement.
- Confirm the problem is a damaged or missing lens rather than failed LED lighting electronics.
- Do not substitute LDCO lens part 228152 based on appearance.
- Do not substitute older LDO, LSO, or LCO lens covers without confirmed compatibility.
- Confirm current package contents if mounting hardware or additional pieces are required.
Installation and Service Notes
Disconnect AC power and battery backup before removing operator covers or working around internal components. Avoid touching energized electronics or moving operator components while replacing the light lens.
After the lens is installed, verify that it is securely mounted and does not interfere with the operator housing, wiring, or lighting components.
If the repair requires internal electrical diagnosis, control-board service, power-supply testing, or work on the integrated LED electronics, use a qualified garage door technician. Do not bypass photo eyes, door reversal protection, wall-control safety functions, or other required safety systems during service.
Product Questions & Answers
What garage door opener does Linear HAE00084 fit?
Current Nice/Linear replacement-parts documentation identifies HAE00084 as the light lens assembly for the Nice/Linear 661 garage door operator using the LINEAR600 service-parts platform.
Is HAE00084 an LED light or just the light lens?
HAE00084 is identified by Nice/Linear as the light lens assembly. The Linear 661 has integrated LED lighting, but HAE00084 should not be treated as the complete LED lighting electronics unless the current package specifically includes additional components.
Is the Linear 661 lighting system rated at 800 lumens?
Yes. Nice/Linear specifies integrated LED lighting rated at 800 lumens for the complete Linear 661 operator. That rating applies to the operator lighting system, not to HAE00084 as a replacement lens.
Will HAE00084 fit Linear LDCO800, LDCO801, or LDCO850 openers?
Do not use HAE00084 for those operators based only on appearance. Current Linear replacement-parts documentation identifies part 228152 as the light lens for LDCO800, LDCO801, and LDCO850.
Will replacing HAE00084 fix a Linear 661 light that does not turn on?
Not necessarily. HAE00084 is the lens assembly. A lighting failure can involve the LED electronics, control board, power supply, wiring, wall station, or another electrical component and should be diagnosed before replacing the lens.
Does HAE00084 include a replacement light bulb?
No conventional replacement bulb is required for the Linear 661 because the operator uses integrated LED lighting. HAE00084 is the replacement light lens assembly.
Does HAE00084 include mounting hardware?
The manufacturer replacement-parts list confirms the HAE00084 light lens assembly but does not separately itemize mounting hardware. Confirm current package contents if specific clips, screws, or additional pieces are required.
What should I verify before ordering Linear HAE00084?
Confirm the opener is a Linear 661, verify HAE00084 in the operator replacement-parts diagram, compare the existing lens shape and mounting points, and determine whether the problem is physical lens damage or an electrical lighting failure.
