Miller Edge Cegard-Max-114NA-W 6ft Heigh, IP65 114 Beam, 10ft Receiver Cable
The Miller Edge Cegard-Max-114NA-W-IP65 is a long range Cegard-Max light curtain used to create a multi-beam photo-optic detection field across a door or access opening. This configuration is listed as a 6 ft. high, 114-beam, IP65 version with a 10 ft. receiver cable. It is selected when the existing system calls for Cegard-Max-114NA-W with the IP65 environmental rating. Correct model matching matters because Cegard-Max systems use specific transmitter, receiver, cable, height, beam count, and environmental options that should not be mixed without confirming the full system configuration.
Common Applications and Replacement Reasons
- Used when a Cegard-Max IP65 light curtain is damaged, misaligned, failed, or being replaced with the same model family
- Important for applications needing a tall multi-beam detection field rather than a single photo eye
- Selection depends on model, height, beam count, cable configuration, and IP rating
Features & Specifications
| Manufacturer | Miller Edge |
|---|
| Product Type | Long range light curtain |
|---|
| Part Number | Cegard-Max-114NA-W-IP65 |
|---|
| Product Family | Cegard-Max |
|---|
| Height | 6 ft. |
|---|
| Beam Count | 114 beams |
|---|
| Enclosure Rating | IP65 |
|---|
| Receiver Cable | 10 ft. receiver cable listed with this configuration |
|---|
| Application | Photo-optic safeguarding for compatible Cegard-Max door or access openings |
|---|
| Compatible Accessory | Cegard-Max-RX-EXT-10 receiver extension for IP65 version only |
|---|
| Notes | Match height, beam count, rating, and cable configuration before replacement |
|---|
Compatible With
- Miller Edge Cegard-Max long range light curtain systems using the 114NA-W IP65 configuration
- Cegard-Max 6 ft. height applications requiring 114 beams
- Cegard-Max receiver-side installations using the IP65 receiver cable configuration
- Cegard-Max-RX-EXT-10 receiver cable extension when used with the IP65 version
- Cegard-Max-Cover light curtain shield kit where a one-side shield is needed
- Not automatically interchangeable with the IP67 version because the environmental rating and accessory compatibility may differ
- Not a replacement for Invisi-Guard-2, IG2, Cegard/Mini, or other photo eye families unless the entire system is redesigned and documented
Also Known As / Related Part Numbers
- Cegard-Max-114NA-W-IP65
- Cegard Max 114NA W IP65
- Cegard-Max 114NA-W IP65
- ME-Cegard-Max-114NA-W-IP65
- Cegard-Max 6 ft. 114 beam IP65
- Related: Cegard-Max-114NA-W-IP67
- Related: Cegard-Max-RX-EXT-10
- Related: Cegard-Max-Cover
Technician Note
Confirm whether the site uses the IP65 or IP67 version before ordering. The IP65 version is the one associated with the Cegard-Max-RX-EXT-10 receiver extension, while the IP67 version should be treated as a separate configuration unless Miller Edge documentation confirms the accessory match.
Before Ordering Checklist
- Confirm the existing label shows Cegard-Max-114NA-W-IP65 or an equivalent IP65 configuration
- Match the 6 ft. height and 114-beam specification
- Confirm receiver cable routing and length before ordering accessories
- Inspect transmitter and receiver alignment hardware before replacing the curtain
- Do not bypass the light curtain input to keep the door running
Professional Advisory
Light curtains are safety devices. If wiring, alignment, or operator safety inputs are unclear, have a qualified door, gate, or access-control technician service the system and confirm proper stop or reverse operation after installation.
Product Questions and Answers
What is the Miller Edge Cegard-Max-114NA-W-IP65?
It is an IP65 Cegard-Max long range light curtain listed as 6 ft. high with 114 beams and a 10 ft. receiver cable configuration.
Is this the same as the IP67 version?
No. The IP65 and IP67 versions should be treated as separate configurations because the environmental rating and accessory compatibility can differ.
Which receiver extension is associated with the IP65 version?
The Cegard-Max-RX-EXT-10 is listed as a 10 ft. receiver cable extension for the IP65 Cegard-Max version only.
Can this replace a regular photo eye?
Not as a simple drop-in replacement. A light curtain has a different detection field, wiring layout, and mounting requirement than a single-beam photo eye.
What should be checked before ordering this light curtain?
Check the model label, height, beam count, IP rating, cable length, and whether the existing system uses matching Cegard-Max transmitter and receiver components.
