AES EL00C-B, 4x "AA" Batteries wrapped - Replacement for Commercial eLoop Lithium Ion
The AES EL00C-B is a wrapped 4 x AA 3.6V replacement battery pack for select AES commercial e-Loop exit and presence detection systems. It is commonly used when an AES EL00C-style commercial e-Loop requires the correct battery pack to maintain reliable wireless vehicle detection performance.
This battery pack supports the power needs of the compatible commercial e-Loop sensor. In the correct system, the e-Loop detects vehicle presence or exit movement and communicates wirelessly with the matching AES receiver or transceiver used by the gate control system.
The EL00C-B should be ordered by exact part number and installed e-Loop model. Do not choose this battery only by voltage, battery count, or physical appearance, because AES e-Loop products can use different battery formats, wiring, polarity, wrapping, and model-specific battery requirements.
What This Replacement Battery Pack Does
The EL00C-B provides replacement battery power for compatible AES commercial e-Loop sensors. When the original battery pack is weak, expired, disconnected, damaged, or unable to hold the required operating voltage, the e-Loop may stop detecting reliably or may stop communicating with the receiver.
This battery pack does not repair the complete detection system by itself. Vehicle detection still depends on the e-Loop electronics, receiver or transceiver, pairing, radio range, installation location, housing condition, magnet setup, and the connected gate operator input.
Compatible With
Use the AES EL00C-B only where the installed loop, parts list, product label, or AES documentation confirms this exact battery pack is required. Compatibility depends on the e-Loop model, battery compartment, lead configuration, polarity, voltage, and battery type.
- Select AES EL00C commercial e-Loop applications where EL00C-B is listed as the replacement battery
- Select AES EL00C-RAD commercial e-Loop applications where the documentation confirms the same 4 x AA 3.6V battery format
- Select AES commercial exit e-Loop applications requiring a wrapped 4 x AA 3.6V battery pack
- Select AES commercial presence e-Loop applications requiring the same EL00C-B battery format
- Repairs where the original battery pack is marked, listed, or cross-referenced as EL00C-B
- Service work where the existing battery configuration, polarity, and lead style match the EL00C-B replacement
- Applications where the e-Loop electronics, receiver pairing, and gate operator input have been confirmed operational
Important Compatibility Warning
Do not replace this battery pack with standard AA alkaline batteries, loose lithium cells, rechargeable consumer AA batteries, or a generic field-made battery pack unless AES documentation confirms the exact specification. Battery voltage, chemistry, discharge behavior, wrapping, lead configuration, and polarity matter on wireless e-Loop sensors.
The EL00C-B is commonly listed as a 4 x AA 3.6V battery pack for commercial e-Loop systems. Before publishing or ordering, verify the exact battery chemistry, connector or lead style, polarity, wrapping, and package configuration from the physical battery label or AES documentation.
Similar AES Battery Parts That Are Not Automatically Interchangeable
- AES EL00C-B: Wrapped 4 x AA 3.6V battery pack for select commercial e-Loop applications.
- AES EL00IG-B: Related 3.6V D battery replacement for commercial in-ground e-Loop applications; not the same as EL00C-B.
- AES EL00M battery references: Mini e-Loop battery requirements may differ and should not be substituted for EL00C-B.
- AES EL00C-SPARES-KIT: 3mm hex key, bolt, and magnet service kit; not a battery replacement.
- AES EL00C-MAG: Magnet reference for EL00C service work; not the same as the battery pack.
- AES EL00C detector-only items: Complete e-Loop detector or sensor products are not the same as the replacement battery pack.
- Generic 4 x AA 3.6V battery packs: May not match the correct lead style, polarity, wrapping, current behavior, or AES-approved format.
Not Intended For
- Use as a complete AES e-Loop detector or wireless vehicle detection system by itself
- Replacement for an AES receiver, transceiver, shell, magnet, hardware kit, or control electronics
- Replacement for EL00IG-B, EL00M batteries, or batteries used in other AES e-Loop models unless AES documentation confirms compatibility
- Use with standard 1.5V AA batteries or loose consumer batteries
- Repairing receiver pairing problems, weak radio range, water-damaged electronics, damaged housings, or gate operator input issues
- Bypassing monitored gate safety inputs, photo eyes, safety edges, access control wiring, or required entrapment protection
Features & Specifications
| Feature / Specification | Details |
| Manufacturer | AES / AES Global |
| Part Number | EL00C-B |
| Product Type | Replacement commercial e-Loop battery pack |
| Battery Configuration | Wrapped 4 x AA battery pack, where supplied as listed |
| Battery Voltage | 3.6V AA cells, where specified by AES documentation |
| Battery Chemistry | Lithium-ion wording appears in AES commercial e-Loop documentation; verify the exact battery label and replacement pack before publishing rechargeable claims |
| Capacity Reference | 2600 mA / mAh style reference appears in AES documentation; verify exact label before publishing capacity as a final specification |
| Common Application | Select AES commercial e-Loop exit and presence detection applications |
| Associated e-Loop Family | AES EL00C / commercial e-Loop family, where confirmed by parts documentation |
| Included Components | One wrapped 4 x AA 3.6V replacement battery pack unless the product listing or packaging states otherwise |
| Not Included | e-Loop detector, receiver, transceiver, shell, magnet, hardware kit, wiring, gate operator, or complete vehicle detection kit |
Also Known As / Related Part Numbers
- AES EL00C-B
- EL00C-B
- AES Global EL00C-B
- Nice AES EL00C-B
- AES Commercial e-Loop Battery Pack
- AES Commercial Exit e-Loop Battery Pack
- AES Commercial Presence e-Loop Battery Pack
- AES 4 x AA 3.6V Battery Pack
- AES 4x AA Wrapped Battery Pack
- AES Replacement Battery for Commercial e-Loop
- AES Individual Battery for Commercial Exit / Presence e-Loop
- AES-EL00C-B
- EL00CB, possible search variation only; verify exact part number as EL00C-B
- HYS-EL00C-B, related distributor-style SKU format only; verify seller SKU before ordering
- EL00IG-B, related AES 3.6V D battery for in-ground e-Loop applications; not the same as EL00C-B
- EL00C-SPARES-KIT, related service hardware kit; not a battery replacement
- EL00C-MAG, related magnet reference; not the same as the battery pack
Related Parts and Accessories
- AES EL00C, commercial e-Loop detector product reference; not the same as the battery pack
- AES EL00C-SPARES-KIT, 3mm hex key, bolt, and magnet kit for EL00C service work; not a battery
- AES EL00C-MAG, related magnet reference for EL00C setup or service work
- AES EL00IG-B, related 3.6V D battery for commercial in-ground e-Loop applications; not interchangeable unless AES confirms
- AES EL00IG-SPARES-KIT, related service kit for EL00IG in-ground applications; not a battery replacement for EL00C-B
- AES e-Loop receivers and transceivers, where required by the installed vehicle detection system
- AES e-Loop setup magnets and service tools, where required by the installed model
Technician Note
When an AES commercial e-Loop stops working, the battery pack is one of the first items to check, but it is not the only possible cause. Receiver pairing, weak radio range, water intrusion, damaged housing, corroded battery leads, incorrect polarity, low signal strength, or gate operator input problems can all look like a failed battery.
Do not build a replacement pack from loose AA batteries unless the voltage, chemistry, lead style, polarity, insulation, wrapping, and AES requirements are confirmed. Incorrect battery configuration can damage the e-Loop electronics and may create an unsafe or unreliable vehicle detection condition.
Before Ordering, Confirm
- The required part number is EL00C-B.
- The installed loop is an AES commercial e-Loop that uses this battery pack format.
- The original battery is a wrapped 4 x AA 3.6V replacement pack.
- The lead style, connector style, polarity, and battery placement match the original battery pack.
- The repair does not require EL00IG-B, EL00M batteries, or another AES e-Loop battery part.
- The battery issue is not actually caused by receiver pairing, radio range, damaged wiring, corrosion, water intrusion, or gate operator input problems.
- The package contents are confirmed, including whether this is one complete wrapped 4-cell pack or individual replacement cells.
- The battery chemistry and rechargeable status are confirmed before publishing lithium-ion or rechargeable claims.
Installation and Service Notes
- Follow AES service instructions for the installed commercial e-Loop model.
- Power down or open the e-Loop only as directed by the AES service procedure.
- Observe polarity, lead routing, and connector orientation before removing the old battery pack.
- Do not short the battery leads, puncture the cells, crush the pack, or expose the battery pack to excessive heat.
- Do not solder directly to loose cells in the field unless the battery is specifically designed and approved for that procedure.
- Inspect the battery area for water intrusion, corrosion, damaged insulation, loose leads, and cracked housing parts before reassembly.
- After replacement, test e-Loop detection, receiver response, gate activation input, and normal gate operation.
- Do not bypass monitored gate safety inputs, photo eyes, safety edges, access control wiring, or required entrapment protection during testing.
Professional Advisory
A qualified gate technician should service the system if the e-Loop is not detecting vehicles reliably, the receiver is not responding, the gate activates unexpectedly, the operator input behavior is unknown, or required gate safety devices are involved. Replace the battery only with the correct AES-specified part and do not bypass gate safety or access control protections to make the system operate.
Product Questions & Answers
What is the AES EL00C-B used for?
The AES EL00C-B is used as a wrapped 4 x AA 3.6V replacement battery pack for select AES commercial e-Loop exit and presence detection applications.
Is EL00C-B a complete e-Loop detector?
No. EL00C-B is a replacement battery pack only. It does not include the e-Loop detector, receiver, transceiver, shell, wiring, gate operator, or complete vehicle detection system.
How many batteries are in the AES EL00C-B pack?
EL00C-B is commonly listed as a 4 x AA 3.6V battery pack for commercial e-Loop systems. Confirm the exact physical pack and lead configuration before ordering.
Is AES EL00C-B the same as EL00IG-B?
No. EL00C-B is commonly listed as a wrapped 4 x AA 3.6V battery pack for commercial e-Loop applications, while EL00IG-B is a related 3.6V D battery for in-ground e-Loop applications.
Can I replace EL00C-B with standard AA batteries?
No. Do not use standard alkaline AA batteries, loose lithium cells, or generic rechargeable AA batteries unless AES documentation confirms compatibility. The replacement must match the required 3.6V battery type, wiring, polarity, and wrapping.
Will a new EL00C-B fix an e-Loop that is not detecting vehicles?
It may fix the issue if the original battery pack is weak or failed, but detection problems can also be caused by receiver pairing, radio range, water intrusion, damaged housing, corrosion, or gate operator input issues.
What should I check before ordering AES EL00C-B?
Confirm the exact EL00C-B part number, installed e-Loop model, 4 x AA 3.6V battery requirement, lead style, polarity, package contents, and whether the problem is truly battery-related before ordering.
